| SYSTEM |
| Article |
PMB728G840 |
| Name |
MultiBoard |
| System Type |
MultiBoard |
| System Form Factor |
All-in-One |
| Built-in Devices |
Android based PC: ARM Cortex A9 / 1.5GHz / 1.5G RAM / 8G ROM
Intel/Windows 10 Pro based PC |
| PROCESSOR |
| CPU |
Intel® Core™ i7-4790S Processor |
| Internal Clock Rate |
3.2 GHz |
| CPU Core Quantity |
4 |
| Max. CPU Bus Clock Rate |
5 GT/sec |
| CPU Socket Standard |
Socket 1150 |
| CPU Installed Quantity |
1 |
| CPU Maximum Quantity Supports |
1 |
| Installed L2 Cache Memory Storage Capacity |
1 MB |
| Installed L3 Cache Memory Storage Capacity |
8 MB |
| Features |
Supports 22 nm Processors |
| Quantity of Mainboards Supported |
1 |
| MEMORY |
| Memory Type |
DDR3 SDRAM |
| Memory Form Factor |
SODIMM 204-pin |
| Memory Speed |
1333MHz/1600MHz |
| Installed System Memory Storage Capacity |
8 GB |
| Maximum Installable System Memory Storage Capacity |
16 GB |
| STORAGE |
| Storage Type |
Solid State Drive |
| Storage Quantity |
1 |
| Storage Capacity |
256 GB |
| DISPLAY |
| Display Form Factor |
Built-in |
| Display Type |
LED |
| Display Technology |
LED Edge light |
| Viewable Display Diagonal Length |
84" | 213 cm |
| Maximum Resolution |
3840x2160 |
| Image Aspect Ratio |
16:9 |
| Pitch Type |
Dot Pitch |
| Pitch Width |
0.484 mm |
| Image Brightness |
350 cd/m^2 |
| Image Contrast |
1 600 : 1 |
| Maximum Response Time |
8 |
| Image Max. V-View Angle |
178 ° |
| Image Max. H-View Angle |
178 ° |
| Monitor Compliant Standards |
VESA FDMI
RoHS |
| Display Features |
LED Backlight
Infrared Touch-screen, 10 points
Lifetime 30000h
MOHS 7 Steel Glass Protection, 4 mm
Ultra HD |
| VIDEO OUTPUT |
| Video Controller Form Factor |
Plug-in-Card |
| Video Card Installed Quantity |
1 |
| Video Chipset |
Nvidia GeForce GT 730M |
| Video Memory Type |
Video Controller Memory |
| AUDIO OUTPUT |
| Audio Controller Form Factor |
integrated |
| Audio Output Mode |
Stereo |
| Compliant Audio Standards |
High Definition Audio |
| SPEAKER |
| Audio Output Mode |
Stereo |
| Number of Speakers |
2 |
| NETWORKING SPECIFICATIONS |
| Networking Form Factor |
Integrated |
| LAN |
Gigabit Ethernet |
| Wi-Fi |
IEEE 802.11a
IEEE 802.11g
IEEE 802.11n |
| Bluetooth |
Bluetooth 4.0 |
| INTERFACE PROVIDED |
| LAN |
2 (RJ-45) |
| USB2.0 |
8 (4-pin USB (type A)) |
| USB3.0 |
3 (USB 3.0 (type A)) |
| VGA |
5 |
| Composite Video Input |
1 |
| HDMI |
5 |
| Audio Interface |
3 (3.5-mm minijack) |
| S/PDIF-out Coaxial |
1 |
| Audio Line-Out |
1 (3.5-mm minijack) |
| Serial |
1 (RS-232) |
| Headphones |
1 (3.5-mm minijack) |
| Microphone-In |
1 (3.5-mm minijack) |
| Mini DisplayPort |
1 |
| SOFTWARE |
| Software Included |
Prestigio EasiNote
Prestigio EasiSign
Prestigio EasiShow
Prestigio EasiMeeting
Prestigio EasiConnect
Prestigio mClass: mTeacher |
| Name of OS |
Microsoft Windows 10 Professional, Android 4.2 |
| POWER |
| Power Device Type |
Power Supply |
| Power Device Location |
Internal |
| Input Voltage |
AC 100-240 V |
| Input Frequency |
50/60 Hz |
| Power Consumption Operational |
500 W |
| Power Consumption Stand By/Sleep |
0.5 W |
| MISCELLANEOUS |
| Package Type |
Box |
| External Colour |
Black |
| Included Accessories |
3 Writing Pens
Remote Control
Application and Driver Disk
Quick Start Guide
WiFi antenna |
| Cable Included |
Audio Cable
USB Cable
VGA Cable
AC Power Cable |
| ENVIRONMENT |
| Maximum Operating Ambient Temperature |
40 °C |
| Maximum Operating Humidity |
90 % |
| Minimum Operating Ambient Temperature |
0 °C |
| Minimum Operating Humidity |
10 % |
| DIMENSIONS & WEIGHT DEVICE |
| Height (mm) |
1187 mm |
| Depth (mm) |
99 mm |
| Width (mm) |
1980 mm |
| Nominal Weight |
107 kg |
| WARRANTY |
| Warranty Products Returnable |
Yes |
| Warranty Term (month) |
12 month(s) |
